GCS型低壓抽出式開關柜

　　GCS type low-voltage withdrawable switchgear

　　產品型號 ：GCS

　　Product model: GCS

　　結構 ：采用抽出式結構，抽屜回路數有1/2、1、2等多種配置。

　　Structure: Adopting a pull-out structure, the drawer circuit has multiple configurations such as 1/2, 1, 2, etc.

　　材料 ：主要使用工程塑料，部分部件為金屬材料。

　　Material: Mainly using engineering plastics, with some components made of metal materials.

　　特點 ：適用于三相交流頻率為50Hz，額定工作電壓為400V（690V），額定電流為4000A及以下的發電、供電系統，用于動力、配電和電動機集中控制、電容補償等。廣泛應用于發電廠、石油、化工、冶金、紡織、高層建筑等場所。

　　Features: Suitable for power generation and supply systems with a three-phase AC frequency of 50Hz, a rated operating voltage of 400V (690V), and a rated current of 4000A and below. Used for power, distribution, centralized control of motors, capacitor compensation, etc. Widely used in power plants, petroleum, chemical, metallurgical, textile, high-rise buildings and other places.

　　GCK型低壓抽出式開關柜

　　GCK type low-voltage withdrawable switchgear

　　產品型號 ：GCK

　　Product model: GCK

　　結構 ：同樣采用抽出式結構，但小抽屜單元為1/2模數。

　　Structure: The same pull-out structure is used, but the minimum drawer unit is 1/2 module.

　　材料 ：主要使用異型鋼。

　　Material: Mainly uses special-shaped steel.

　　特點 ：適用于較大電流的電動機控制中心和饋電回路。其頂部可裝母線橋，防護等級為IP30。

　　Features: Suitable for motor control centers and feeding circuits with high currents. The top can be equipped with a busbar bridge, with a protection level of IP30.

　　MNS型低壓抽出式開關柜

　　MNS type low-voltage withdrawable switchgear

　　產品型號 ：MNS

　　Product Model: MNS

　　結構 ：采用大聯鎖機構，安裝模數為25mm，可做雙面柜，正反兩均裝抽屜。

　　Structure: Adopting a large interlocking mechanism, with an installation module of 25mm, it can be used as a double-sided cabinet, with drawers installed on both sides.

　　材料 ：主要使用工程塑料，部分部件為金屬材料。

　　Material: Mainly using engineering plastics, with some components made of metal materials.

　　特點 ：適用于小電流場合，安裝模數為25mm，多可做9層抽屜，雙面柜多可裝72個抽屜。

　　Features: Suitable for low current applications, with an installation module of 25mm, it can accommodate up to 9 drawers, and a double-sided cabinet can hold up to 72 drawers.

　　GGD型交流低壓配電柜

　　GGD type AC low-voltage distribution cabinet

　　產品型號 ：GGD

　　Product model: GGD

　　結構 ：固定安裝、固定接線。

　　Structure: Fixed installation, fixed wiring.

　　特點 ：適用于低壓配電，通常為固定式結構，防護等級為IP30。

　　Features: Suitable for low-voltage distribution, usually a fixed structure, with a protection level of IP30.

　　總結與建議

　　Summary and Suggestions

　　在選擇低壓抽屜柜時，應根據具體的應用場景和需求進行選擇。例如，對于需要較高電流承載能力和較多層抽屜的應用場合，GCK和GCS是較好的選擇；而對于小電流、需要較高靈活性和雙面操作的應用場合，MNS更為適用。同時，也要考慮柜體的防護等級、安裝模數以及是否需要與計算機接口等因素。

　　When choosing a low-voltage drawer cabinet, the selection should be based on specific application scenarios and requirements. For applications that require high current carrying capacity and multiple drawers, GCK and GCS are better choices; For applications with low current, high flexibility, and double-sided operation, MNS is more suitable. At the same time, factors such as the protection level of the cabinet, installation module, and whether it needs to interface with a computer should also be considered.

　　本文由山東MNS低壓抽屜柜提供幫助，更多的相關內容請點擊： http://www.ubrp.cn 希望本文能夠為您帶來幫助，感謝您的閱讀！

　　This article is assisted by shandongMNS low-voltage drawer cabinets. For more related content, please click: http://www.ubrp.cn I hope this article can be helpful to you. Thank you for reading!
